SensorStandard
For monitoring temperature and humidity in vehicles, warehouses and containers.
- Temperature, humidity, movement and door opening
- Bluetooth range up to 80 m*
- Battery up to 5 years*
- IP67 sealed casing
- Home
- Temperature and humidity sensor
Your cargo’s temperature and humidity, in real time
A coin-sized Bluetooth sensor that monitors temperature, humidity, movement and door openings. Your Vigilo tracker sends the data to the platform and alerts you as soon as anything goes out of range.
- Temperature and humidity
- Instant alerts
- Up to 5-year battery*
- IP67
- ATEX and EN12830
Cold room 1 · 4.2 °C · 63 % RHIn range · 1 min agoAlert: 9.1 °CVan 4587 LMN · 10:42-20 to +60 °Ctemperature range
0–100 %relative humidity
5 yearsbattery life*
IP67dust and water
What it measures
Four sensors in a single device
Temperature
From -20 °C to +60 °C, with continuous readings and history to prove the cargo travelled at the right temperature.
Humidity
Relative humidity from 0 to 100 %, for goods damaged by condensation or dry air.
Movement and tilt
Detects if goods are moved, dropped or tipped over during transport.
Door opening
With a magnet on the door, you know when and where the cargo area was opened.
How it works
From the sensor to your screen, without cables
The sensor is placed next to the cargo and broadcasts its readings over Bluetooth. The vehicle’s Vigilo tracker receives them and sends them to the platform with the GPS position.
Fit the sensor
With screws, a cable tie or adhesive, in the box, cold room, pallet or cargo area.
The tracker reads it
The Vigilo tracker receives temperature and humidity over Bluetooth, up to 80 m away*.
See data and alerts
The platform shows charts and history and alerts you if temperature or humidity leave the range you set.
Refrigerated van 4587 LMNAllowed range: 2 to 8 °C
4.2 °C63 % RH
- 10:42High temperature: 9.1 °CRear door open for 6 min
- 10:58Temperature back to 6.8 °CIn range
- 13:15Door openedDelivery at City Pharmacy
Models
Three sensors for every type of cargo
SensorATEX
Certified for areas with a risk of gas explosion and for mining.
- ATEX zone 1 (gas) and mining certification
- Same sensors, range and battery
- High-visibility yellow
- IP67 sealed casing
SensorEN12830
Certified temperature recorder for the food and medicine cold chain.
- EN12830 certified, 0.5 °C accuracy class
- Calibrated in an ISO 17025 laboratory
- Internal memory of up to 345 days
- Food-contact safe casing
| Feature | Standard | ATEX | EN12830 |
|---|---|---|---|
| Temperature | -20 °C to +60 °C | -20 °C to +60 °C | -20 °C to +60 °C · 0.5 °C class |
| Relative humidity | 0 to 100 % | 0 to 100 % | 0 to 100 % |
| Movement and tilt | Yes | Yes | Yes |
| Door opening (magnet) | Yes | Yes | Yes |
| EN12830 certification (cold chain) | — | — | Yes · ISO 17025 calibrated |
| Internal memory | — | — | Up to 345 days |
| Explosive atmospheres | — | ATEX zone 1 (gas) and mining | — |
| Casing | Black · IP67 | Yellow · IP67 | White, food-contact safe · IP67 |
| Bluetooth range | Up to 80 m* | Up to 80 m* | Up to 80 m* |
| Battery | Up to 5 years* | Up to 5 years* | Up to 5 years* |
| Size and weight | 56.6 × 38 × 13 mm · 18 g | 56.6 × 38 × 13 mm · 18 g | 56.6 × 38 × 13 mm · 18 g |
* Range depends on the environment (walls, metal, cold rooms). Non-rechargeable battery: 2.5 years sending data every 3 s, 4 years every 5 s (default setting) and 5 years every 10 s. A Vigilo tracker with Bluetooth is required.
What is the EN12830 standard?
It is the European standard for temperature recorders used to transport and store chilled and frozen food and medicines. It requires a calibrated, accurate device whose records serve as evidence for inspections and customers.
Use cases
Logistics and delivery
Pharma and healthcare
Cold chain
How temperature and humidity sensors are used
Logistics and deliveryShipping sensitive electronics
Boards, components and electronic equipment that are damaged by heat, humidity or knocks. The sensor travels with the cargo and records temperature, humidity and movement throughout the journey.
- Alert when humidity rises and condensation is likely
- Detection of drops and impacts
- History for claims against the carrier
Pharma and healthcarePharmaceutical distribution
Medicines and vaccines that must stay between 2 and 8 °C from the warehouse to the pharmacy. With the EN12830 sensor, every delivery is recorded by a certified device.
- Continuous 2 to 8 °C monitoring
- Records valid for inspections
- Instant alert if the cold chain breaks
Cold chainRefrigerated trucks and vans
End-to-end temperature monitoring in refrigerated vehicles, with the GPS position of every reading and a record of every door opening.
- Temperature and position on the same map
- Door openings with time and place
- Reports per trip and per customer
FAQ
Questions about temperature and humidity sensors
How does the data reach the platform?
The sensor sends its readings over Bluetooth to the vehicle’s Vigilo tracker, which forwards them to the platform with its GPS position.
Can I get alerts?
Yes. You set the temperature and humidity range for each sensor and the platform alerts you as soon as a reading goes out of range.
How long does the battery last?
Up to 4 years with the default setting and up to 5 years when sending data every 10 seconds. The battery is not rechargeable.
Which sensor do I need for food or medicines?
The EN12830 model, certified as a cold-chain temperature recorder, laboratory calibrated and with internal memory.
When do I need the ATEX version?
When the sensor will work in areas with a risk of gas explosion, such as chemical plants, refineries or fuel transport, or in mining.
Does it work inside a cold room?
Yes, between -20 °C and +60 °C. Metal walls reduce the Bluetooth range, so we help you decide where to place the sensor and the tracker.
Want your cargo always at the right temperature?
We will prepare a proposal based on your vehicles, cold rooms and type of cargo.
